PS- MNB108(HCBF) 445W – 460WMNB

Features

Warranty Icon

30-Year Linear Power Warranty

Mechanical Load Icon

5400Pa Front / 2400Pa Back Static Mechanical Load Capacity

Reliability Icon

Enhanced 16-Busbar technology for superior reliability

N-Type Icon

Ultra-low annual degradation with N-Type technology (-0.4%)

Temperature Icon

Better temperature coefficients come from half-cell design

Anti-PID Icon

Exceptional anti-PID performance to ensure module’s stable power output

Shading Icon

Less partial shading current mismatch loss so more power output

📄
Download Datasheet (PDF)
EXUS
BrandMNB
Categories

Description Philadelphia Solar’s Mono-Crystalline N-type modules with power up to 460Wp are produced using state-of-the-art (automated) robotic production lines. These modules are suitable to be used for most electrical power applications and have excellent durability to prevailing weather conditions.

BENEFITS

  • Performance Warranty: 25-Year Product Warranty and 30-Year Linear Power Warranty.
  • Bifacial Technology: Power output increases by 5-25% from the backside, resulting in significantly reduced LCOE and (IRR).
  • Efficiency & Reliability: Improved light trapping and current collection technology enhance module power output and reliability.
  • Superior Durability: Exceptional Anti-PID performance through the use of optimized mass-production processes and strict materials control.
  • Mechanical Strength: Built to withstand high mechanical loads of 5400 Pascal (Front) and 5400 Pascal (Back).
  • Annual Degradation: Ultra-low annual power degradation of only -0.4%.

Applications

Residential Solar Icon
On-Grid Residential Roof-Tops
Commercial Solar Icon
On-Grid Commercial / Industrial Roof-Tops
Power Plants Icon
Solar Power Plants
Off-grid Lighting Icon
Off-Grid Systems
(Including Lighting Systems)

Additional information

Weight 20,5 kg
Dimensions 1724 × 1134 × 30 mm
Power Output:

445Wp – 460Wp

Module Efficiency:

Up to 23.53%

Cell Type:

N Type Mono-Crystalline

Cells per Module:

108 (54 x 2)

Front Surface:

3.2mm Tempered AR Coated Glass

Junction Box:

IP 68 with original MC4

Mechanical Load:

Front (5400 Pascal) and Back (5400 Pascal)

Product manual:

Included in the package

Origin:

Made In Jordan

  • What makes the 460W series unique for residential projects?

    • It combines the highest efficiency in its class (23.53%) with a lightweight design (20.5 kg), making it perfect for maximizing energy on small rooftops.


  • How many modules are in a 40-foot container for this model?

    • A 40-foot High-Cube container fits 962 modules, with 37 modules per pallet.


  • Does this module handle extreme weather well?

    • Yes, it is certified to withstand a massive 5400 Pascal load on both the front and back, providing exceptional resistance to heavy snow and wind.


  • What is the annual power degradation rate?

    • The module has an extremely low annual degradation of only -0.4%, ensuring 87.4% of its original power even after 30 years.
